Juice Manual Mechanical Homogenizer High Throughput Homogenizer

Juice Manual Mechanical Homogenizer High Throughput Homogenizer

  • Juice Manual Mechanical Homogenizer High Throughput Homogenizer
  • Juice Manual Mechanical Homogenizer High Throughput Homogenizer
  • Juice Manual Mechanical Homogenizer High Throughput Homogenizer
  • Juice Manual Mechanical Homogenizer High Throughput Homogenizer
Juice Manual Mechanical Homogenizer High Throughput Homogenizer
Product Details:
Place of Origin: China
Brand Name: SAMRO
Certification: ISO
Model Number: SRH200-120
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: plywood with iron base package
Delivery Time: 20-30 working days after receiving down payment
Payment Terms: T/T
Supply Ability: 50 sets per month
Contact Now
Detailed Product Description
Name: Manual Homogenizer Capacity: 200 L/H
Max Pressure: 120 Mpa Normal Working Presure: 0-96 Mpa
Weight: 1000 KG Motor: 11 KW
Type: High Throughput Homogenizer Size: 125*90*100 Cm
High Light:

High Throughput Homogenizer

,

Manual Mechanical Homogenizer

,

Juice Mechanical Homogenizer

Juice Manual Homogenizer , OEM Emulsion High Throughput Homogenizer



Manual Homogenizer Main technical parameters:



Model

SRH200-120

Rated flow: L/H

200

Max pressure: Mpa

120

Normal working pressure: Mpa

0-96

Inlet pressure: Mpa

0.2-0.3

Adaptable material feeding temperature / viscosity

100℃/≤1000CP

Rated motor power: KW

11

Size: cm

125*90*100

Weight: KG

1000

Lubricating oil

L-HM100 OR Mobil SHC627(ISO VG100)

Housing Material

Stainless steel

Plunge Sealing Material

packing

Pressure gauge

Diaphragm

Support material

shaped steel





Manual Homogenizer Function:



Homogenizers are an innovative alternative that provides solutions in the food, pharmaceutical and cosmetic industry for the preparation of suspensions, microemulsions, nanoencapsulation and cell lysis. The homogenization causes the rupture of the fatty globules thus decreasing their size and stabilizing the emulsion of the fat against the separation by gravity. The disintegration of the globules is achieved by the combination such as turbulence and cavitation.



Manual Homogenizer Application:



● Cosmetics & Toiletries: cream, lotion, wax, mascara, gel, toothpaste
● Pharmaceuticals: ointment, dental composite, syrup, injection
● Food: mayonnaise, salad dressing, casda sauce, west point sauce

● Chemicals: polyester, synthetic fiber, shoe cream



Juice Manual Mechanical Homogenizer High Throughput Homogenizer 0

Homogenizer Applications:



Food and Drink:

Enzymes, dressing, tomato sauce, fruit paste, butter oil, drink, dairy drink, Ice cream, baby food, chocolate, flavors and fragrances, milk powder.



Chemical:

Disinfectants, emulsifiers, fuel oil, insecticides, oants, oil emulsions, silicone emulsions, wax emulsions, lubricants, resins/rosins, latex, viscosity Improvers.



Biotechnology:

Cell disruption of yeast, E.coil other bacteria and algae.



Pharmaceutical:

Antibiotics, skin cream, intravenous, emulsion, ointments, tablet coatings, lipostiomes



Cosmetics:

Hair products, skin creams, lotions, perfumes, shampoos and conditioners.



Types of Homogenizer:



Manual Operating Homogenizer:

Two- stage homogenizer system with manual pressure adjustment is easy to use. It is your economic choice.



Hydraulic Operating Homogenizer:

The hydraulic control system is developed to adjust the homogenizer pressure, and it is easy to upgrade to remote control system by changing to Proportional valves.



Pneumatic Operating Homogenizer:

The pneumatic control system is developed for the homogenizer, and it is easy to upgrade to remote control.



Large Capacity Homogenizer:

This machine has five plungers with the maximum flow reaching 30000L/H. The hydraulic end adopts the split structure which facilitates assembly and disassembly. The pressure adjustment can adopt manual or hydraulic mode.



Laboratory Homogenizer:

Capacity: 60L/H Max Pressure</=70MPa

Minimum Sample Volume: 200ml

Two-stage Homogenizing



Qustions you may have about our company:



1. Are you a new company?

Actually, we have 20 years experience specialized in high pressure homogenizer. We are the most famous manufacture of high pressure homogenizer in China and we have very good reputation in China. Now we want to develop new area and bring high quality homogenizer with competitive price to overseas.



2. Do you have different pressure from the mentioned one?

Yes, we have different pressure homogenizer from 20-150Mpa. And the capacity could be different, too. You can tell us the requirement of the pressure and capacity, our technician will check if we can meet your demand. And our sales will offer you rather good price.



3. What’s the meaning of your Model No.?

We think example can make you understand more quickly. For example, our model SRH1000-30, SRH means SAMRO Homogenizer, 1000 means the capacity of each hour is 1000L, 30 means the max pressure of this model.



We are a 20 years original specialized factory here. Leave us an inquiry to know more details according to the different models you need.
