Mechanical Process Milk Homogenization , Liquid Homogenizer Automatic Cleaning
  • Mechanical Process Milk Homogenization , Liquid Homogenizer Automatic Cleaning
  • Mechanical Process Milk Homogenization , Liquid Homogenizer Automatic Cleaning
  • Mechanical Process Milk Homogenization , Liquid Homogenizer Automatic Cleaning

Mechanical Process Milk Homogenization , Liquid Homogenizer Automatic Cleaning

Place of Origin China
Brand Name SAMRO
Certification ISO
Model Number SRH200-120
Product Details
Capacity:
200 L/H
Max Pressure:
120 Mpa
Motor:
11 KW
Size:
125*90*100 Cm
Warranty Time:
12 Months
Name:
Liquid Homogenizer
High Light:

Ice Cream Homogenizer machine

,

milk homogenization

,

Automatic Cleaning Liquid Homogenizer

Payment & Shipping Terms
Minimum Order Quantity
Negotiable
Price
Negotiable
Packaging Details
plywood with iron base package
Delivery Time
20-30 working days after receiving down payment
Payment Terms
T/T
Supply Ability
50 sets per month
Product Description

Mechanical Process Milk Homogenization , Liquid Homogenizer Automatic Cleaning



Liquid Homogenizer Introduction


Liquid Homogenizer is the mechanical process where raw materials are put under high pressure and broken down into smaller particles.
This equipment can be used widely in production, research and technical development of food, milk extract, drink, pharmacy, fine chemical, biotechnology and other fields.
Many kinds of material such as milk or bean milk can be homogenized under high pressure to considerably thin the fat balls in the milk liquid, which makes the products be easy to be digested and absorbed, and improve the edibleness.
This equipment can be used in the production of ice cream to improve the thinness and fraction void of liquid material.

Our company has rich experience to help customers to establish the different production lines for different use, for example. we can arrange technical staff to help customer set up whole production line for mineral water, pure water,coca-cola, milk, juice and vinegar,oil, we are profession for making it. If anyone who is interested in such field wants to buy the whole equipments and machines, pls contact us freely.



Liquid Homogenizer parameters:



Model

SRH200-120 Liquid Homogenizer

Rated flow: L/H

200

Max pressure: Mpa

120

Normal working pressure: Mpa

0-96

Inlet pressure: Mpa

0.2-0.3

Adaptable material feeding temperature / viscosity

100℃/≤1000CP

Rated motor power: KW

11

Size: cm

125*90*100

Weight: KG

1000

Lubricating oil

L-HM100 OR Mobil SHC627(ISO VG100)

Housing Material

Stainless steel

Plunge Sealing Material

packing

Pressure gauge

Diaphragm

Support material

shaped steel



Homogenizer Applications:



Food and Drink:

Enzymes, dressing, tomato sauce, fruit paste, butter oil, drink, dairy drink, Ice cream, baby food, chocolate, flavors and fragrances, milk powder.



Chemical:

Disinfectants, emulsifiers, fuel oil, insecticides, oants, oil emulsions, silicone emulsions, wax emulsions, lubricants, resins/rosins, latex, viscosity Improvers.



Biotechnology:

Cell disruption of yeast, E.coil other bacteria and algae.



Pharmaceutical:

Antibiotics, skin cream, intravenous, emulsion, ointments, tablet coatings, lipostiomes



Cosmetics:

Hair products, skin creams, lotions, perfumes, shampoos and conditioners.

Mechanical Process Milk Homogenization , Liquid Homogenizer Automatic Cleaning 0



Qustions you may have about our company:



1. Are you a new company?

Actually, we have 20 years experience specialized in high pressure homogenizer. We are the most famous manufacture of high pressure homogenizer in China and we have very good reputation in China. Now we want to develop new area and bring high quality homogenizer with competitive price to overseas.



2. Do you have different pressure from the mentioned one?

Yes, we have different pressure homogenizer from 20-150Mpa. And the capacity could be different, too. You can tell us the requirement of the pressure and capacity, our technician will check if we can meet your demand. And our sales will offer you rather good price.



3. What’s the meaning of your Model No.?

We think example can make you understand more quickly. For example, our model SRH1000-30, SRH means SAMRO Homogenizer, 1000 means the capacity of each hour is 1000L, 30 means the max pressure of this model.



We are a 20 years original specialized factory here. Leave us an inquiry to know more details according to the different models you need.
