| Place of Origin: | CHINA |
| Brand Name: | SAMRO |
| Certification: | ISO |
| Model Number: | SRH3000-30 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | plywood package with iron base |
| Delivery Time: | 20-30 working days after receiving down payment |
| Payment Terms: | T/T |
| Supply Ability: | 50 sets per month |
| Model: | Dairy Homogenizer | Material: | Stainless Steel |
|---|---|---|---|
| Max Pressure: | 30 Mpa | Normal Working Pressure: | 0-24 Mpa |
| Motor: | 30 KW | Size: | 150*110*120 Cm |
| Weight: | 1800 KG | Type: | Hydraulic |
| High Light: | Hydraulic Milk Homogeniser,Ice Cream Milk Homogeniser,Stainless Steel Milk Homogeniser |
||
Stainless Steel Chemical Hydraulic Dairy Homogenizer
Introduction
This types of homogenizer is a kind of equipment, which make a mixture of two or more substance mixed equally. It could improve the stability of the liquid and taste. Homogenized liquid is more smooth and more easily digestible. The homogenizer could be used for milk,ice cream, fruit, herb drink and so on.
Main function of homogenizer machine include: improve homogeneity and stability of products, increase the period of maintenance and reduce reaction time, so as to save the
mass of activator and color.
This machine is a special device for liquid even and convey under high voltage.
It widely used in foods, milk, beverage, making medicine and other technological sectors.
For Cream and other products, it can improve the fine clean degree of liquid and gas porosity, mak ing its inner quality has improved significantly.
If it is used in emulsion, glue, fruit juice, slurry and other production, it can help prevent or reduce the layered material liquid and then improve the look of the material liquid .
Finally, make the color more beautiful.
Dairy Homogenizer Applications:
Food and Drink
Enzymes, dressing, tomato sauce, fruit paste, butter oil, drink, dairy drink, Ice cream, baby food, chocolate, flavors and fragrances, milk powder.
Chemical
Disinfectants, emulsifiers, fuel oil, insecticides, oants, oil emulsions, silicone emulsions, wax emulsions, lubricants, resins/rosins, latex, viscosity Improvers.
Biotechnology
Cell disruption of yeast, E.coil other bacteria and algae.
Pharmaceutical
Antibiotics, skin cream, intravenous, emulsion, ointments, tablet coatings, lipostiomes
Samro Homogenizer Main model:
| NO. | Machine | Piston | Working | MAX Working | Continual | Power | Weight | Size |
| Model | radix | rate | Pressure | Working | KW | Kg | L×W×H | |
| (Liters/Hr) | (Bar)MPa | Pressure | M | |||||
| (Bar) | ||||||||
| 1 | SRH60-70 | 1 | 60 | 70 | 0-56 | 3 | 270 | 0.7×0.4×1.3 |
| 2 | SRH250-70 | 3 | 250 | 70 | 0-56 | 5.5 | 700 | 1.2×0.8×1.0 |
| 3 | SRH500-35/45/70 | 3 | 500 | 35/45/70 | 0-28/36/56 | 5.5/7.5/11 | 700/750/800 | 1.2×0.8×1.0 |
| 4 | SRH1000-35/45 | 3 | 1000 | 35/45 | 0-28/36 | 11or15 | 800/850 | 1.2×0.8×1.3 |
| 5 | SRH1000-70 | 3 | 1000 | 70 | 0-56 | 22 | 1500 | 1.2×0.9×1.4 |
| 6 | SRH1500-30/60 | 3 | 1500 | 30/60 | 0-24/48 | 15/30 | 850/1800 | 1.2×0.8×1.3 |
| 7 | SRH1500-90 | 3 | 1500 | 90 | 0-72 | 45 | 2800 | 1.6×1.1×1.6 |
| 8 | SRH2000-25/30 | 3 | 2000 | 25/30 | 0-20/24 | 15/22 | 1500 | 1.2×0.9×1.4 |
| 9 | SRH2000-40 | 3 | 2000 | 40/45 | 0-32 | 30 | 1800 | 1.3×0.9×1.5 |
| 10 | SRH2000-70 | 3 | 2000 | 70 | 0-56 | 45 | 2800 | 1.6×1.1×1.6 |
| 11 | SRH2500-40 | 3 | 2500 | 40 | 0-32 | 37 | 1800 | 1.2×0.8×1.4 |
| 12 | SRH3000-25/30 | 3 | 3000 | 25/30 | 0-20/24 | 30 | 1600/1800 | 1.3×0.9×1.5 |
| 13 | SRH3000-40 | 3 | 3000 | 40 | 0-32 | 37 | 1800 | 1.7×1.1×1.5 |
| 14 | SRH3000-55 | 3 | 3000 | 55 | 0-44 | 55 | 2800 | 1.6×1.1×1.6 |
| 15 | SRH3000-70 | 4 | 3000 | 70 | 0-56 | 75 | 3000 | 1.7×1.5×1.3 |
| 16 | SRH3500-40 | 3 | 3500 | 40 | 0-32 | 45 | 2800 | 1.6×1.1×1.6 |
| 17 | SRH3500-50 | 3 | 3500 | 50 | 0-40 | 55 | 2800 | 1.6×1.1×1.6 |
| 18 | SRH4000-25/30 | 3 | 4000 | 25/30 | 20/24 | 37/40 | 1800 | 1.7×1.1×1.5 |
| 19 | SRH4000-40 | 3 | 4000 | 40 | 0-32 | 55 | 2800 | 1.6×1.1×1.6 |
| 20 | SRH4000-60 | 3 or 4 | 4000 | 60 | 0-48 | 75 | 3000 | 1.7×1.5×1.3 |
| 21 | SRH4000-70 | 4 | 4000 | 70 | 0-56 | 90 | 3000 | 1.7×1.5×1.3 |
| 22 | SRH5000-25/30 | 3 | 5000 | 30 | 0-20/24 | 45/55 | 2800 | 2.3×1.1×1.4 |
| 23 | SRH5000-45 | 4 | 5000 | 45 | 36 | 75 | 4000 | 1.7×1.5×1.3 |
| 24 | SRH5000-70 | 4 | 5000 | 70 | 56 | 110 | 4500 | 1.8×1.5×1.4 |
| 25 | SRH6000-25/30 | 3 or 4 | 6000 | 25/30 | 0-20/24 | 55/75 | 4000 | 1.7×1.5×1.3 |
| 26 | SRH6000-40 | 4 | 6000 | 40 | 0-32 | 75 | 4500 | 1.7×1.5×1.3 |
| 27 | SRH6000-55 | 4 | 6000 | 55 | 0-44 | 110 | 5000 | 1.8×1.5×1.4 |
| 28 | SRH7000-25/35 | 3 or 4 | 7000 | 25/35 | 20/28 | 55/75 | 4000 | 1.7×1.5×1.3 |
| 29 | SRH7500-30 | 4 | 7000 | 30 | 0-24 | 75 | 4500 | 1.7×1.5×1.3 |
| 30 | SRH8000-25/30 | 3 or 4 | 8000 | 25/30 | 0-20/24 | 75 | 4000 | 1.7×1.5×1.3 |
| 31 | SRH8000-40 | 4 | 8000 | 40 | 0-32 | 110 | 5000 | 1.8×1.5×1.4 |
| 32 | SRH10000-25 | 4 | 10000 | 25 | 0-20 | 90 | 4500 | 1.8×1.5×1.4 |
| 33 | SRH10000-35 | 4 | 10000 | 35 | 0-28 | 110 | 5000 | 1.8×1.5×1.4 |
| 34 | SRH10000-40 | 4 | 10000 | 40 | 0-32 | 132 | 5000 | 2.2×1.6×1.4 |
| 35 | SRH10000-45 | 4 | 10000 | 45 | 0-36 | 132 | 5000 | 2.2×1.6×1.4 |
| 36 | SRH12000-30 | 4 | 12000 | 30 | 0-24 | 110 | 4500 | 1.8×1.5×1.4 |
| 37 | SRH12000-40 | 4 | 12000 | 40 | 0-32 | 132 | 5000 | 2.2×1.6×1.4 |
| 38 | SRH14000-30 | 4 | 14000 | 30 | 0-24 | 132 | 5000 | 2.2×1.6×1.4 |
| 39 | SRH15000-23 | 4 | 15000 | 23 | 0-18 | 110 | 5000 | 2.2×1.6×1.4 |
| 40 | SRH16000-40 | 4 | 16000 | 40 | 0-32 | 200 | 5500 | 2.2×1.8×1.4 |
| 41 | SRTH20000-30 | 4 | 20000 | 30 | 0-24 | 200 | 5500 | 2.2×1.8×1.4 |
